Stainless Steel  Liquid  Storage  Tank  Chemical  Storage  Tank

Stainless Steel Liquid Storage Tank Chemical Storage Tank
Specifications - ISO tank container manufacturers
Frame Dimensions (L x W x H)6058 x 2438 x 2591 mm
Nominal Capacity25000 litre (±0.75%)
Maximum Gross Mass36000 kgs
Tare Mass 3510 kg (± 3%)
Design Temperature (Frame & Tank)-40 to +130 °C
PressureWorking 1.70 bar
 Test2.65 bar
MaterialTank (Shell & Ends) SANS 50028-7 Type 1.4402/1.4404 (C≤0.03%)
 FrameSPA-H or equivalent
InsulationShellRockwool (50kg/m3) 50mm thick on aluminium foil.
 EndsGlasswool (16kg/m3) thickness to suit on aluminium foil.

Steam Heating
6 runs.
110mm width stainless steel 304.
1" BSP inlet, 1" BSP outlet both with captive caps and cable.
4 bar working pressure, 6 bar test with warning decals and markings.
A condensate drain is fitted.
Manhole500mm low profile, 8 point fixing with Super Tanktyt Lid seal.

Safety Relief
2½" BSP Supermaxi Highflow relive, without flameproof gauze.
Pressure only set at +4.4 bar (63.8psi).
The assembly is situated off centre on a tangential tank pad.
Air Inlet

DN 40 ball valve terminating with 1½" BSP connection and cap.
The assembly is situated off centre on a tangential tank pad.
Top Discharge
DN80 stainless steel 316 tank pad with a blind flange.
The assembly is fitted on centre on a horizontal tank pad.
DN80 45° Univalve Internal Footvalve part no. TBC fitted with an integrated butterfly
valve terminating with a 3" BSP spigot with 3" BSP blind cap and chain.
ThermometerA surface mounted analogue type is fitted to the rear end dished end of the tank. Dual
scale -40°C to +160°C / -40°F to 320°F. The thermometer is fitted with a protection bar.
A clear plastic document holder ø110mm is fitted to the rear right hand side beam.
A drain hole is provided at the lowest point.
CalibrationA calibration plate marked in cm/litres is fitted on the spillbox side wall.
No calibrated stainless steel grade dipstick and bracket fitted.
Design CodeASME VIII DIV. 1
ApprovalIMDG, US DOT CFR 49, RID/ADR, CSC, TC, TIR / Customs, UIC, ISO 1496/3
1. Inner layer - made of 6 or 8 mm thick Q235-B steel plate, compared with ordinary 5 mm thick single-layer tank, the strength is greatly improved;

2. Outer layer - tempered glass fiber thickness of 4.0mm or more, good compressive and seismic resistance. It has strong corrosion resistance and corrosion resistance;

3.Unique technology is adopted between the inner and outer layers to make it reach a gap of 0.1-1mm, so as to eliminate hidden dangers from the root;

4. Leak detector 24 hours to monitor, to prevent leakage caused by security risks;

5. Widely used for storage and transportation in dairy, beverage, wine technology, with function of anti-seismic, anti-explosion, leakage-proof and cooling.

Detailed photos for the Tank container:
Stainless Steel Liquid Storage Tank Chemical Storage Tank

Factory Workshop:
Stainless Steel Liquid Storage Tank Chemical Storage Tank

3.More Styles for the ISO tanker container:

Stainless Steel Liquid Storage Tank Chemical Storage Tank

4.Design proposal for the 20feet ISO tank container:
---Net capacity: not less than 20cubic; Shell of tank container Materials using Wisco Q235 High quality carbon steel 6mm baffle;
---Two feed inlets,bigger manhole covers, 2 NOS. pressure vent valves( breather valve) , at the end of the bottom , DN80 dump valve(discharge valve). Screw of Openings and valves adopt stainless steel screws, single coaming board on the top of tank Molybdenum red reflective tape;
---Framework is made of High quality steel, each one ladder at back and forth. With two acid resistant tube, two 4kg fire extinguishers.

5.Optional parts for the tanker container:
Volume: 20 cube meters to 52 cube meters
Material: Carbon steel/aluminum/stainless steel material
HYDROFLUDRIC ACID HCI 32%,CAUSTIC SODA NaOH 32%,NaCl. NaClO etc. Chemical Liquid.

Henan Jushixin Transportation Equipment Co.Ltd is the professional manufacturer of ISO tank container,such as standard liquid tanks, electrical heating tanks, reefer tanks, food grade tanks, baffle tanks, swap tanks, gas tanks, H2O2 tanks, AHF tanks, bitumen tanks, different types of lining tanks, etc, and 10ft tanks, offshore tanks, IBC/SBC ,etc, with high standard machinery and automatic equipment, powerful R&D team and elite sales team, we have built a long business relationship with many world famous enterprises.pls contact us if any interset.
Stainless Steel Liquid Storage Tank Chemical Storage Tank

Stainless Steel Liquid Storage Tank Chemical Storage Tank

>>>Offering the one-stop full lifecycle services;
>>>Our vehicle users will receive 24-hour uninterruptible "Entire Journey" service;

>>>CCC&ISO Agreement, 1 Year Guarantee Term, Main-beam Lifetime Promise;
>>> Small Order Can Be Accepted;
>>>Any Color & Logo Available;
>>>The Product Dimension + Specifications Can Be Designed As Your Needs.

8.Buying Guides
**You please send us your enquiry;
**We shall reply you with the quotation within 12 hours;
**We negotiate on the configuration that you need;
**Confirmation of the tech data → sign contract (P/I) → 30% deposit (or L/C issuing)→ production;
**Manufacturing process updated news → completing production;
**Balance payment → ex works → shipment → custom clearance → A/S service for 1 year.
